Quality standards and classification CE, ISO13485 SFDA: Class II b Anti-electroshock degree: Class I equipment (internal power supply) TEMP/Sp02 /NIBP: BF ECG/Resp: CF |
Application Range Adult/Pediatric/Neonatal/Medicine/Surgery/ Operating Room/ICU/CCU |
Display 15” real color TFT screen |
Environment Operating environment: Temperature: 0~40°C Humdidty: 15%~80% Pressure: 86.0kPa~106.0kPa Transport and Storage environment: Temperature: -20~55°C Humdidty: 10%~90% Pressure: 86.0kPa~106.0kPa |
Power Requirements AC: 100~240V,50Hz/60Hz DC: Built-in rechargeable battery Battery: 11.1V 24wh Li-ion battery 2h operating after full charge 5min operating after low battery alarm |
Dimension and Weight Equipment: 360mm*162mm*321mm; 4.47kg Package: 420mm*380mm*321mm; 7.3kg |
Date Storage Trend diagram/table:7x24h NIBP review: 400 events Wave review: 100min Alarm review: 100 alarm events Support drug concentration titration analysis |
ST Segment ST Segment range: -2.0mV~+2.0mV Accuracy: 0.02mV |
ECG 5 Leads: RA, LA, LL, RL, V Lead mode: I, II, III, aVR, aVL, aVF, V Increase: x250, x500, x1000, 2000 Sensitivity: >200 uV (Peak-to-peak value) Input impedance: >5 (megohm) Bandwidth: Surgery 1~20Hz, Monitor 0.5~40Hz Diagnostic 0.05~130Hz CMRR: ≥100dB Polarization Voltage: ±300mV Baseline Recovering Time: After defibrillation<3 seconds Signal Range: 8mV (Peak-to-peak value) Calibrating Signal: 1mV, precision ±5% |
RESP Method: RA-LL impedance Resp Impedance range: 0.3~3Ω Base Impedance range: 200Ω~4000Ω Bandwidth: 0.1~2.5Hz Resp rate: Adult: 0~120BrPM Neonatal/Pediatric: 0~150BrPM Resolution: 1BrPM Precision: ±2BrPM Asphyixa Alarm: 10~40 seconds |
NIBP Method: Pulse wave oscillometry Work mode: Manual/Auto/STAT Measure interval of auto mode: 1,2,3,4,5,10,15,30,60,90,120,180,240,480min Measuring time of STAT mode: 5min PR range: 40~240bpm Measure & alarm range: Adult: SYS 40~270mmHg DIA 10~215mmHg MEAN 20~235mmHg Pediatric: SYS 40~200mmHg DIA 10~150mmHg MEAN 20~165mmHg Neonatal: SYS 40~135mmHg DIA 10~100mmHg MEAN 20~110mmHg Static pressure range: 0~300mmHg Precision: ±3mmHg Pressure precision:Max. average error: ±5mmHg Max. standard deviation: ±8mmHg Overvoltage protection: Adult 300mmHg Pediatric 240mmHg Neonatal 150mmHg |
SpO2 Range: 0~100% Resolution: 1% Precision: 70%~100%: ±2 DIGIT 0%~69%: ±no definition given |
Pulse Rate Range: 20~300bpm Resolution: 1bpm Precision: ±3bpm |
TEMP Channel: 2 Measure & alarm range: 0~50°C Resolution: 0.1°C Presision (no sensor): ±0.1°C |
Standard accessories · NIBP cuff & tube · ECG cable & electrodes · SpO2 sensor · TEMP probe · Lithium-ion battery · Power cable · Operator’s manual |
Optional accessories · CO2 module · IBP module · Trolley bracket · Hanging bracket · Monitor recorder |
IBP Label ART, PA, CVP, RAP, LAP, ICP, P1, P2 Measuring and alarm range ART: 0~300mmHg PA: -6~120mmHg CVP/RAP/LAP/ICP: -10~40mmHg P1/P2: -10~300mmHg Press Sensor Sensitivity: 5 uV/V/mmHg Impedance: 300~3000Ω Resolution: 1mmHg Accuracy: ±2% or ±1mmHg, which great Actualization interval: about 1 Sec |
CO2 Side/Main stream Measurement Infrared radiation absorption technique Measurement range: 0~99mmHg Precision 0-40mmHg: ±2mmHg 41-76mmHg: ±5% 77-99mmHg: ±10% Resolution: 1mmHg Pumping rate: 70ml/min, 100ml/min Accuracy: 15% or 15ml/min big AwRR measuring range: 0~120BrPM Precision: 0~70BrPM: ±2BrPM >70BrPM: ±5BrPM |
